13. Remove the sensor(s).
Note: The sensors are identical.
Sensor (lower media exit) removal
1. Open the finisher front door assembly.
2. Remove the upper media bin assembly. See “Upper media bin assembly removal” on page 4-352.
3. Disconnect the connector from the sensor (lower media exit) (A).
4. Remove the harness from the clamps.
C
A
B
C
A
Connector
