Diagnostic information 2-179
5058-030
401.05 Sensor (bridge media entrance) lag jam
6
Check the bridge drive motor
connection.
Is the above motor properly
connected?
Replace the bridge drive motor.
Go to “Bridge drive motor
removal” on page 4-230.
Go to step 6.
Replace the connection.
7
Perform a print test. Go to
“PRINT TESTS” on page 3-22.
Does the error remain?
Replace the bridge unit interface
card assembly.
Go to step 7.
Problem resolved
8
Perform a print test. Go to
“PRINT TESTS” on page 3-22.
Does the error remain?
Replace the finisher PCBA.
Go to “Finisher PCBA removal”
on page 4-281.
Problem resolved
Step Action and questions Yes No
1 Check the media path.
Is the media path free of any
media fragments?
Go to step 2. Remove any media or media
fragments.
2
Check the bridge unit media
transport rollers.
Are the bridge unit media
transport rollers free of excess
wear and contamination?
Go to step 3. Clean or replace the bridge unit
assembly.
Go to “Bridge unit assembly
removal” on page 4-232.
3
Check the sensor (bridge media
entrance) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch SENSOR TESTS.
3. Touch FINISHER SENSOR
TESTS.
4. Touch Sensor (bridge media
entrance).
Does the display on the
operator panel change every
time the sensing area of the
above sensor is interrupted or
blocked?
Go to step 5. Go to step 4.
4
Check the sensor (bridge media
entrance) for proper connection.
Is the above sensor properly
connected?
Replace the sensor (bridge
media entrance).
Go to “Sensor (bridge media
entrance) removal” on
page 4-240.
Replace the connection.
Step Action and questions Yes No
