2-124 Service Manual
5058-030
245.56 Sensor (HCF feed out) late jam
9
Check the the HCF controller
card PCBA for proper connection.
Is the above component
properly connected?
Replace the HCF controller card
PCBA. Go to “HCF controller
card PCBA removal” on
page 4-432.
Go to step 10.
Replace the connections.
10
POR the machine, and perform a
print test. Go to “PRINT TESTS”
on page 3-25.
Does the error continue?
Replace the upper printer engine
PCBA.
Go to “Upper printer engine
PCBA removal” on page 4-189.
Problem resolved
Step Action and questions Yes No
1 Check the media path.
Is the media path free of any
media fragments?
Go to step 2. Remove any media or media
fragments.
2
Check the feed rollers for wear.
Is the above component free of
excess wear and damage?
Go to step 3. Replace the HCF feed rollers.
Go to “HCF feed roll assembly
removal” on page 4-361.
3
Check the transport rollers for
wear.
Is the above component free of
excess wear and damage?
Go to step 4. Replace the HCF transport
rollers.
Go to “HCF transport roller kit
removal” on page 4-380.
4
Check the sensor (tray 4 feed
out) for proper connection.
Is the above component
properly connected?
Clean or replace the sensor (tray
4 feed out). Go to
“Sensor (tray
module feedout) removal” on
page 4-200.
Replace the connection.
5
Check the HCF feed/lift motor for
proper operation.
When performing
motor tests, ensure
that all cover and
door interlock
switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch PRINTER MOTOR
TESTS.
4. Touch HCF feed/lift motor
(feed).
5. Touch HCF feed/lift motor
(lift).
Does the above component
operate properly?
Go to step 7. Go to step 6.
Step Action and questions Yes No
To Next Page
