Diagnostic information 2-123
5058-030
3
Check the transport rollers for
wear.
Is the above component free of
excess wear and damage?
Go to step 4. Replace the transport rollers.
Go to “HCF transport roller kit
removal” on page 4-452.
4
Check the sensor (tray 5 feed
out) for proper connection.
Is the above component
properly connected?
Clean or replace the sensor (tray
5 feed out). Go to “HCF sensor
(tray 5 feedout) removal” on
page 4-446.
Replace the connection.
5
Check the HCF feed/lift motor for
proper operation.
When performing
motor tests, ensure
that all cover and
door interlock
switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch PRINTER MOTOR
TESTS.
4. Touch HCF feed/lift motor
(feed).
5. Touch HCF feed/lift motor
(lift).
Does the above component
operate properly?
Go to step 7. Go to step 6.
6
Check the HCF feed lift motor for
proper connection.
Is the above component
properly connected?
Replace the HCF feed lift motor.
Go to
“HCF feed lift motor
removal” on page 4-433.
Replace the connections.
7
Check the HCF transport motor
for proper operation.
When performing
motor tests, ensure
that all cover and
door interlock
switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch PRINTER MOTOR
TESTS.
4. Touch HCF transport motor.
Does the above component
operate properly?
Go to step 9. Go to step 8.
8
Check the HCF transport motor
for proper connection.
Is the above component
properly connected?
Replace the HCF transport
motor. Go to
“HCF transport
motor removal” on page 4-452.
Replace the connections.
Step Action and questions Yes No
