2-98 Service Manual
5058-030
202.05 Sensor (fuser exit) lag jam
6
Check the lower redrive shift
motor assembly for proper
operation.
When performing
motor tests, ensure
that all cover and
door interlock
switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch PRINTER MOTOR
TESTS.
4. Touch Lower redrive shift
motor (forward).
5. Touch Lower redrive shift
motor (reverse).
Does the above component
operate properly?
Go to step 8. Go to step 7.
7
Check the lower redrive shift
motor assembly for proper
connection.
Is the above component
properly connected?
Replace the lower redrive shift
motor assembly.
Go to “Lower redrive shift
motor assembly removal” on
page 4-99.
Replace the connection.
8
Check the fuser/lower redrive/1st
transfer retract motor for proper
operation.
When performing
motor tests, ensure
that all cover and
door interlock
switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch PRINTER MOTOR
TESTS.
4. Touch Fuser/lower redrive/
1st transfer retract motor.
Does the above component
operate properly?
Go to step 8. Go to step 9.
9
Check the fuser/lower redrive/1st
transfer retract motor for proper
connection.
Is the above component
properly connected?
Replace the fuser/lower redrive/
1st transfer retract motor.
Go to “Fuser/lower redrive/1st
BTR retract motor removal” on
page 4-91.
Replace the connection.
10
Perform a print test. Go to
“PRINT TESTS” on page 3-22.
Does the error continue?
Replace the upper printer engine
PCBA.
Go to “Upper printer engine
PCBA removal” on page 4-181.
Problem resolved
Step Action and questions Yes No
