Diagnostic information 2-93
5058-030
202.01 Sensor (fuser exit) static jam
10
Check the registration clutch for
proper operation.
When performing
motor tests, ensure
that all cover and
door interlock
switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch PRINTER MOTOR
TESTS.
4. Touch Registration clutch.
Does the above component
operate properly?
Go to step 12. Go to step 11.
11
Check the registration clutch for
proper connection.
Is the above component
properly connected?
Replace the registration transport
roller assembly.
Go to “Registration/transport
roller assembly removal” on
page 4-143.
Replace the connection.
12
Perform a print test. Go to
“PRINT TESTS” on page 3-22.
Does the error continue?
Replace the lower engine PCBA.
Go to “Lower engine PCBA
removal” on page 4-98.
Problem resolved
Step Action and questions Yes No
1 Check the media path.
Is the media path free of any
media fragments?
Go to step 2. Remove any media or media
fragments.
2
Check the sensor (fuser exit) for
proper operation.
1. Enter the Diagnostics Menu.
2. Touch SENSOR TESTS.
3. Touch PRINTER SENSOR
TESTS.
4. Touch Sensor (fuser exit).
Does the display on the
operator panel change every
time the sensing area of the
above sensor is interrupted or
blocked?
Go to step 4. Go to step 3.
3
Check the sensor (fuser exit) for
proper connection.
Is the above component
properly connected?
Replace the fuser assembly.
Go to “Fuser assembly
removal” on page 4-78.
Replace the connection.
Step Action and questions Yes No
To Next Page
