Diagnostic information 2-167
5058-030
381.34 Sensor (booklet rear tamper HP) lag jam
7
Check the booklet rear tamper
motor for proper operation.
When performing
motor tests, ensure
that all cover and
door interlock
switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch FINISHER MOTOR
TESTS.
4. Touch Booklet tamper rear
motor (forward).
5. Touch Booklet tamper rear
motor (reverse).
Does the above component
operate properly?
Go to step 6. Go to step 5.
8
Check the booklet tamper rear
motor.
Is the above component
properly connected?
Replace the booklet rear tamper
motor. Go to
“Booklet rear
tamper motor removal” on
page 4-260.
Replace the connection.
9
Perform a POR.
Does the error continue when
the power is turned off/on?
Replace the booklet controller
card assembly. Go to
“Booklet
controller card assembly
removal” on page 4-250.
Problem resolved
10
Perform a POR.
Does the error continue when
the power is turned off/on?
Replace the finisher PCBA. Go to
“Finisher PCBA removal” on
page 4-281.
Problem resolved
Step Action and questions Yes No
1 Check the booklet unit interface
connector assembly.
Is the above component free of
damage?
Go to step 2. Replace the booklet unit interface
contact.
2
Check the main connector on the
booklet unit sensor interface
cable assembly.
Is the above component free of
damage?
Go to step 3. Replace the booklet sensor
interface cable assembly.
3
Check the main connector on the
booklet unit motor interface cable
assembly.
Is the above component free of
damage?
Go to step 4. Replace the booklet motor
interface cable assembly.
Step Action and questions Yes No
To Next Page
