2-168 Service Manual
5058-030
4
Check the booklet rear tamper by
moving it manually.
Does the above component
slide back and forth properly?
Go to step 5. Remove obstructions.
5
Check the sensor (booklet rear
tamper HP) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch SENSOR TESTS.
3. Touch FINISHER SENSOR
TESTS.
4. Touch Sensor (booklet rear
tamper HP.
Does the display on the
operator panel change every
time the sensing area of the
above sensor is interrupted or
blocked?
Go to step 7. Go to step 6.
6
Check the sensor (booklet rear
tamper HP).
Is the sensor (booklet rear
tamper HP) properly
connected?
Replace the sensor (booklet rear
tamper HP). Go to “Sensor
(booklet rear tamper HP)
removal” on page 4-316.
Replace the connection.
7
Check the booklet rear tamper
motor for proper operation.
When performing
motor tests, ensure
that all cover and
door interlock
switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch FINISHER MOTOR
TESTS.
4. Touch Booklet tamper rear
motor (forward).
5. Touch Booklet tamper rear
motor (reverse).
Does the above component
operate properly?
Go to step 6. Go to step 5.
8
Check the booklet rear tamper
motor.
Is the above component
properly connected?
Replace the booklet rear tamper
motor. Go to
“Booklet rear
tamper motor removal” on
page 4-260.
Replace the connection.
9
Perform a POR.
Does the error continue when
the power is turned off/on?
Replace the booklet controller
card assembly. Go to “Booklet
controller card assembly
removal” on page 4-250.
Problem resolved
Step Action and questions Yes No
