2-90 Service Manual
5058-030
200.55 Sensor (registration) lag jam
See “200.05/200.55 Sensor (registration) lag jam” on page 2-85.
201.01 Sensor (media on belt) static jam
13
Check the tray module lower
transport motor for proper
operation.
When performing
motor tests, ensure
that all cover and
door interlock
switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch PRINTER MOTOR
TESTS.
4. Touch 1TM/3TM/TTM lower
transport motor.
Does the above component
operate properly?
Go to step 7. Go to step 6.
14
Check the tray module lower
transport motor for proper
connection.
Is the above component
properly connected?
Replace the tray module lower
transport motor.
Go to “Tray module lower
transport motor removal” on
page 4-207.
Replace the connection.
15
Perform a print test. Go to
“PRINT TESTS” on page 3-22.
Does the error continue?
Replace the lower engine PCBA.
Go to “Lower engine PCBA
removal” on page 4-98.
Problem resolved
Step Action and questions Yes No
1 Check the media path.
Is the media path free of any
media fragments?
Go to step 2. Remove any media or media
fragments.
2
Check the sensor (media on belt )
for proper operation.
1. Enter the Diagnostics Menu.
2. Touch SENSOR TESTS.
3. Touch PRINTER SENSOR
TESTS.
4. Touch Sensor (paper on
belt).
Does the display on the
operator panel change every
time the sensing area of the
above sensor is interrupted or
blocked?
Go to step 4. Go to step 3.
Step Action and questions Yes No
