Lexmark C950 - Finisher Removal

Repair information 4-283
5058-030
Go Back
Previous
Next
Finisher removal
1. Disconnect the finisher power cord and the finisher connection cable from the rear of the printer.
2. Release the hook securing the bridge unit hookup cover (A) to the finisher.
3. Remove the bridge unit hookup cover (A).
4. Disconnect the bridge unit connection from the finisher.
5. Open the finisher front door assembly (B) on the front of the finisher.
Right
Rear
A
Hook
