Diagnostic information 2-203
5058-030
492.01 Sensor (booklet compiler media present) static jam
5
Check the booklet unit interface
contact for proper connection.
Is the above component
properly connected?
Go to Step 6. Replace the booklet unit interface
contact.
6
Check the booklet controller card
assembly for proper connection.
Is the above component
properly connected?
Replace the booklet controller
card assembly).
Go to “Booklet controller card
assembly removal” on
page 4-250.
Go to step 7.
Replace the connections.
7
POR the machine.
Does the error continue?
Replace the finisher PCBA.
Go to “Finisher PCBA removal”
on page 4-281.
Problem resolved
Step Action and questions Yes No
1 Check the media path.
Is the media path free of any
media fragments?
Go to step 2. Remove any media or media
fragments.
2
Check the sensor (booklet
compiler media entrance) for
proper operation.
1. Enter the Diagnostics Menu.
2. Touch SENSOR TESTS.
3. Touch FINISHER SENSOR
TESTS.
3. Touch Sensor (booklet
compiler media present).
Does the display on the
operator panel change every
time the sensing area of the
above sensor is interrupted or
blocked?
Go to Step 4. Go to Step 3.
3
Check the sensor (booklet
compiler media entrance) for
proper connection.
Is the above component
properly connected?
Replace the sensor (booklet
compiler media entrance). Go to
“Sensor (booklet compiler
media entrance) removal” on
page 4-311.
Replace connections.
4
Check the booklet controller card
assembly for proper connection.
Is the above component
properly connected?
Replace the booklet controller
card assembly).
Go to “Booklet controller card
assembly removal” on
page 4-250.
If the error remains, then go to
step 5.
Replace the connections.
Step Action and questions Yes No
To Next Page
