Booklet staple position fine adjustment (3-14 sheets)
Step Check Yes No
1 Note: The booklet staple position fine adjustment is
different depending on the amount of sheets that compose
the booklet.
Volume 1 = 3 sheets
Volume 2 = 4 sheets
Volume 3 = 5-7 sheets
Volume 4 = 8-14 sheets
Print the appropriate booklet using the booklet maker.
Does the staple position fine adjustment appear to be offset
from the fold as shown in the graphic below?
Go to step 2. The booklet staple
position fine
adjustment is in
spec.
