5-34 Service Manual
5058-030
Go Back
Previous
Next
Finisher—stapler
Plug/Jack Callout Plug/jack description Connects to
P/J8354 3 Complete stapler Finisher controller PCBA
P/J8356 1 Stapler unit assembly Finisher controller PCBA
P/J8357 4 Stapler unit assembly Finisher controller PCBA
P/J8358 2 Stapler transport motor Finisher controller PCBA
