Lexmark C950 - Heat Belt (Rear) Disconnection Error; Heat Belt (Rear) Overheat Error

2-48 Service Manual
5058-030
Go Back
Previous
Next
121.05 Heat belt (rear) disconnection error
121.06 Heat belt (rear) overheat error
3
POR the machine.
Does the error continue?
Replace the upper printer engine
PCBA.
Go to “Upper printer engine
PCBA removal” on page 4-181.
Problem resolved
Step Action and questions Yes No
1 Check the fuser assembly.
Is the above component
properly connected?
Go to step 2. Remove foreign particles, and
replace the connections.
2
Replace the fuser assembly. Go
to
“Fuser assembly removal”
on page 4-78.
Does the error remain?
Go to step 3. Problem resolved
3
POR the machine.
Does the error continue?
Replace the upper printer engine
PCBA.
Go to “Upper printer engine
PCBA removal” on page 4-181.
Problem resolved
Step Action and questions Yes No
1 Check the heat roll.
Is the heat roll free of any
media or foreign particles?
Go to step 2. Remove foreign particles, and
replace the connections.
2
Check the fuser assembly.
Is the above component
properly connected?
Go to step 3. Replace the connections.
3
Replace the fuser assembly. Go
to
“Fuser assembly removal”
on page 4-78.
Does the error remain?
Go to step 4. Problem resolved
4
POR the machine.
Does the error continue?
Replace the upper printer engine
PCBA.
Go to “Upper printer engine
PCBA removal” on page 4-181.
Problem resolved
Step Action and questions Yes No
