Booklet fold position fine adjustment (3-15 sheets)
Step Check Yes No
1 Note: The booklet fold position fine adjustment is different
depending on the amount of sheets that compose the
booklet and the size of the media.
Volume 1 = 3 sheets
Volume 2 = 4 sheets
Volume 3 = 5-7 sheets
Volume 4 = 8-15 sheets
S = media < B4
L = B4 media or >
Print the appropriate booklet using the booklet maker.
Do the booklet sheet edges appear overlapped as shown in
the graphic below?
Go to step 2. The booklet fold
position fine
adjustment is in
spec.
