Lexmark C950 - Sub LVPS PCBA Removal

4-158 Service Manual
5058-030
Go Back
Previous
Next
3. Remove the sensor (printer tray 1 prefeed).
4. Disconnect the cable (B).
Sub LVPS PCBA removal
1. Remove the rear upper cover. See “Rear upper cover removal” on page 4-16.
2. Disconnect the input option cable (A).
