Diagnostic information 2-87
5058-030
200.53 Sensor (registration) late jam (80K interval exceeded for feed rollers)
8
Check the Media Transport/MPF
drive motor assembly for proper
operation.
When performing
motor tests, ensure
that all cover and
door interlock
switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch PRINTER MOTOR
TESTS.
4. Touch Media Transport/MPF
drive motor.
Does the above component
operate properly?
Go to step 10. Go to step 9.
9
Check the media transport/MPF
drive motor assembly for proper
connection.
Is the above component
properly connected?
Replace the media transport/
MPF drive motor assembly.
Go to “Media transport/MPF
drive motor removal” on
page 4-118.
Replace the connection.
10
POR the machine.
Does the error continue?
Replace the lower engine PCBA.
Go to “Lower engine PCBA
removal” on page 4-98.
Problem resolved
Step Action and questions Yes No
1 Check the media path.
Is the media path free of any
media fragments?
Go to step 2. Remove any media or media
fragments.
2
Replace the pick/feed rollers. Go
to “Pick roller removal” on
page 4-135.
Does the jam continue?
Go to step 3.
Problem resolved
3
Check the sensor (registration)
for proper operation.
1. Enter the Diagnostics Menu.
2. Touch SENSOR TESTS.
3. Touch PRINTER SENSOR
TESTS.
4. Touch Sensor (registration).
Does the display on the
operator panel change every
time the sensing area of the
above sensor is interrupted or
blocked?
Go to Step 5. Go to step 4.
Step Action and questions Yes No
