2-88 Service Manual
5058-030
4
Check the sensor (registration)
for proper connection.
Is the above component
properly connected?
Replace the media transport/MPF
drive motor.
Go to “Media transport/MPF
drive motor removal” on
page 4-118.
Replace the connections.
5
Check the registration drive motor
for proper operation.
When performing
motor tests, ensure
that all cover and
door interlock
switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch PRINTER MOTOR
TESTS.
4. Touch Registration motor.
Does the above component
operate properly?
Go to step 7. Go to step 6.
6
Check the registration drive motor
for proper connection.
Is the above component
properly connected?
Replace the registration drive
motor.
Go to “Registration drive motor
removal” on page 4-141.
Replace the connection.
7
Check the media feed lift motor
assembly for proper operation.
When performing
motor tests, ensure
that all cover and
door interlock
switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch PRINTER MOTOR
TESTS.
4. Touch Tray [x] feed/Lift
motor (feed).
5. Touch Tray [x] feed/Lift
motor (lift).
Does the above component
operate properly?
Go to step 9. Go to step 8.
8
Check the media feed lift motor
for proper connection.
Is the above component
properly connected?
Replace the media feed lift motor.
Go to “Media feed lift motor
removal” on page 4-115.
Replace the connection.
Step Action and questions Yes No
