2-20 Service Manual
5058-030
191.17
Service engine error
Lower engine PCBA fuse 13 blown A fuse has blown.
Go to “191.17 Lower engine PCBA fuse
13 blown” on page 2-79.
191.18
Service engine error
Upper engine PCBA data failure Data values are not normal on the upper
engine memory.
Go to “191.18 Upper engine PCBA data
failure” on page 2-79.
191.19
Service engine error
Upper engine PCBA access failure Data values are not normal on the upper
engine memory.
Go to “191.19 Upper engine PCBA
access failure” on page 2-80.
191.20
Service engine error
Upper engine PCBA buffer failure Data values are not normal on the upper
engine memory.
Go to “191.20 Upper engine PCBA
buffer failure” on page 2-80.
191.23
Service engine error
Fuse 14 on the Lower Engine PCBA
has blown.
Go to “191.23 Lower engine PCBA fuse
14 blown” on page 2-80.
191.24
Service engine error
Fuse 15 on the Lower Engine PCBA
has blown.
Go to “191.24 Lower engine PCBA fuse
15 blown” on page 2-81.
191.25
Service engine error
Fuse 16 on the Lower Engine PCBA
has blown.
Go to “191.25 Lower engine PCBA fuse
16 blown” on page 2-81.
2xx service error codes
Error code Description Action
200.01
Paper jam
Sensor (registration) static jam Media remains detected by the sensor
(registration) after power on.
Go to “200.01 Sensor (registration)
static jam” on page 2-81.
200.03
Paper jam
Sensor (registration) late jam (feeding
from the tray)
The media is late reaching the sensor
(registration) within the specified time after
the registration clutch is turned on.
Go to “200.03 Sensor (registration) late
jam (feeding from the tray)” on
page 2-82.
200.03
Paper jam
Sensor (registration) late jam (feeding
from the MPF)
The media is late reaching the sensor
(registration) within the specified time after
the MPF pick solenoid is turned on.
Go to “200.03 Sensor (registration) late
jam (feeding from the MPF)” on
page 2-84.
1xx service error codes
Error code Description Action
