Diagnostic information 2-85
5058-030
200.05/200.55 Sensor (registration) lag jam
6
Check the media transport/MPF
drive motor for proper operation.
When performing
motor tests, ensure
that all cover and
door interlock
switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch PRINTER MOTOR
TESTS.
4. Touch MPF feed/lift motor
(pick)
5. Touch MPF feed/lift motor
(feed).
Does the above component
operate properly?
Go to step 8. Go to step 7.
7
Check the MPF feed/lift motor for
proper connection.
Is the above component
properly connected?
Replace the media transport/MPF
drive motor.
Go to “Media transport/MPF
drive motor removal” on
page 4-118.
Replace the connection.
8
POR the machine, and perform a
PRINT test.
Go to “PRINT TESTS” on
page 3-22.
Does the error continue?
Replace the lower engine PCBA.
Go to “Lower engine PCBA
removal” on page 4-98.
Problem resolved
9
POR the machine, and perform a
PRINT test.
Go to “PRINT TESTS” on
page 3-22.
Does the error continue?
Replace the upper printer engine
PCBA.
Go to “Upper printer engine
PCBA removal” on page 4-181.
Problem resolved
Step Action and questions Yes No
1 Check the media path.
Is the media path free of any
media fragments?
Go to step 2. Remove any media or media
fragments.
2
Check the registration/transport
roller assembly.
Is the above component free of
excess wear and
contamination?
Go to step 3. Clean or replace the registration/
transport roller assembly.
Go to “Registration/transport
roller assembly removal” on
page 4-143.
Step Action and questions Yes No
To Next Page
