4-174 Service Manual
5058-030
Go Back
Previous
Next
Transfer belt lever removal
1. Open the front door.
2. Rotate the transfer belt lever counterclockwise to the unlock position.
3. Remove the screw (A) from the transfer belt lever.
A
