Lexmark C950 - Assembly 17: Photoconductor

7-18 Service Manual
5058-030
Go Back
Previous
Next
Assembly 17: Photoconductor
Asm-
index
Part
number
Units/
mach
Units/
FRU
Description
17-1 40X6636 41Erase lamp
2 40X6634 41PC smart chip cover
3 40X6633 41PC smart chip holder
4 40X6635 41PC smart chip socket
5 40X6640 11Torsion spring
6 40X6638 11Belt lever lock
7 40X6639 11Belt lock bracket
8 40X6641 11Plate spring
9 40X6637 11Inner plate
1
4
2
3
3
3
3
7
6
5
8
9
