Connector locations 5-31
5058-030
Go Back
Previous
Next
TTM—tray 2/3/4 media size sensor
Plug/Jack Callout Plug/jack description Connects to
P/J101 1
Media size switch PCB
Tray module controller PCBA
P/J102 3
Media size switch PCB
Tray module controller PCBA
P/J103 2
Media size switch PCB
Tray module controller PCBA
