2-190 Service Manual
5058-030
484.01 Sensor (compiler media present) static jam
8
Check the buffer diverter gate
solenoid for proper operation.
When performing
motor tests, ensure
that all cover and
door interlock
switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch FINISHER MOTOR
TESTS.
4. Touch Buffer diverter gate
solenoid.
Does the above component
operate properly?
Go to step 10. Go to step 9.
9
Check the buffer diverter gate
solenoid for proper connection.
Is the above component
properly connected?
Replace the buffer diverter gate
solenoid.
Go to “Buffer diverter gate
solenoid removal” on
page 4-266.
Replace the connection.
10
Check the finisher PCBA for
proper connection.
Is the above component
properly connected?
Go to Step 11. Replace the connections.
11
POR the machine.
Does the error continue?
Replace the finisher PCBA.
Go to “Finisher PCBA removal”
on page 4-281.
Problem resolved
Step Action and questions Yes No
1 Check the media path.
Is the media path free of any
media fragments?
Go to step 2. Remove any media or media
fragments.
2
Check the Sensor (compiler
media present) for proper
operation.
1. Enter the Diagnostics Menu.
2. Touch SENSOR TESTS.
3. Touch FINISHER SENSOR
TESTS.
4. Touch Sensor (compiler
media present).
Does the display on the
operator panel change every
time the sensing area of the
above sensor is interrupted or
blocked?
Go to Step 3. Go to Step 2.
Step Action and questions Yes No
