Diagnostic aids 3-31
5058-030
203 paper jam
If the jammed paper is visible in the standard exit bin, then firmly grasp the paper on each side, and then gently
pull it out.
Note: Make sure all paper fragments are removed.
1. Open door A and then door D by lifting the release latch of each door and lowering the doors.
2. Firmly grasp the jammed paper on each side, and then gently pull it out.
Note: Make sure all paper fragments are removed.
3. Close door D, and then close door A.
4. If necessary, touch Continue from the printer control panel.
CAUTION—HOT SURFACE:
The inside of the printer might be hot. To reduce the risk of injury from a hot component, allow
the surface to cool before touching.
