Diagnostic information 2-153
5058-030
381.15 Sensor (punch side reg 1/2) lag jam
9
Check the sensor (stacker bin
level encoder) for proper
connection.
Is the above component
properly connected?
Replace the sensor (stacker bin
level encoder). Go to “Sensor
(stacker bin level encoder)
removal” on page 4-330.
Replace the connection.
10
Check the stacker bin lift motor
for proper operation.
When performing
motor tests, ensure
that all cover and
door interlock
switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch FINISHER MOTOR
TESTS.
4. Touch Stacker bin lift motor
(up).
5. Touch Stacker bin lift motor
(down).
Does the above component
operate properly?
Go to step 12. Go to step 11.
11
Is the stacker bin lift motor
connected properly?
Replace the stacker bin lift motor.
Go to “Stacker bin lift motor
assembly removal” on
page 4-337.
Replace the connection.
12
Perform a POR.
Does the error continue when
the power is turned off/on?
Replace the finisher PCBA. Go to
“Finisher PCBA removal” on
page 4-281.
Problem resolved
Step Action and questions Yes No
1 Check the sensor (punch unit
side reg 1) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch SENSOR TESTS.
3. Touch FINISHER SENSOR
TESTS.
4. Touch Sensor (punch side
reg 1).
Does the display on the
operator panel change every
time the sensing area of the
above sensor is interrupted or
blocked?
Go to step 3. Go to step 2.
Step Action and questions Yes No
To Next Page
