Diagnostic information 2-201
5058-030
2
Check the sensor (booklet media
entrance) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch SENSOR TESTS.
3. Touch FINISHER SENSOR
TESTS.
4. Touch Sensor (booklet
media entrance).
Does the display on the
operator panel change every
time the sensing area of the
above sensor is interrupted or
blocked?
Go to Step 4. Go to Step 3.
3
Check the sensor (booklet media
entrance) for proper connection.
Is the above component
properly connected?
Replace the sensor (booklet
media entrance).
Go to “Sensor (booklet media
entrance) removal” on
page 4-315.
Replace connections.
4
Check the booklet media
entrance drive motor for proper
operation.
When performing
motor tests, ensure
that all cover and
door interlock
switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch SENSOR TESTS.
3. Touch FINISHER MOTOR
TESTS.
4. Touch Booklet entrance
motor.
Does the display on the
operator panel change every
time the sensing area of the
above sensor is interrupted or
blocked?
Go to Step 6. Go to Step 5.
5
Check the booklet media
entrance drive motor for proper
connection.
Is the above component
properly connected?
Replace the booklet media
entrance drive motor assembly.
Go to “Booklet media entrance
drive motor removal” on
page 4-257.
Replace connections.
6
Check the booklet controller card
assembly for proper connection.
Is the above component
properly connected?
Replace the booklet controller
card assembly).
Go to “Booklet controller card
assembly removal” on
page 4-250.
If the error remains, then go to
step 7.
Replace connections.
Step Action and questions Yes No
To Next Page
