Lexmark C950 Service Manual

Diagnostic information 2-207
5058-030
Go Back
Previous
Next
4
Check the booklet folding/exit
motor for proper connection.
Is the above component
properly connected?
Replace the booklet folding/exit
motor.
Go to “Booklet folding/exit
drive motor assembly removal”
on page 4-254.
Replace connections.
5
Check the booklet fold solenoid
for proper operation.
When performing
motor tests, ensure
that all cover and
door interlock
switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch FINISHER MOTOR
TESTS.
4. Touch Booklet knife
solenoid.
Does the above component
operate properly?
Go to step 7. Go to step 6.
6
Check the booklet fold solenoid
for proper connection.
Is the above component
properly connected?
Replace the booklet fold
solenoid. Go to “Booklet fold
solenoid removal” on
page 4-253.
Replace the connection.
7
Check the booklet controller card
assembly for proper connection.
Is the above component
properly connected?
Replace the booklet controller
card assembly).
Go to “Booklet controller card
assembly removal” on
page 4-250.
If the error remains, then go to
step 8.
Replace the connections.
8
Check the finisher PCBA for
proper connection.
Is the above component
properly connected?
Go to step 9. Replace the connections.
9
POR the machine.
Does the error continue?
Replace the finisher PCBA.
Go to “Finisher PCBA removal”
on page 4-281.
Problem resolved
