Lexmark C950 - Page 728

4-300 Service Manual
5058-030
Go Back
Previous
Next
8. Remove the screw securing the eject clamp lever assembly (C) from the shaft (D) on the rear of the
finisher.
9. Remove the eject clamp lever assembly (C).
10. Remove the e-clip securing the shaft (D) to the rear of the finisher.
11. Remove the 8 mm bushing (E) on the rear side.
12. Remove the e-clip securing the shaft (F) to the front of the finisher.
Rear
C
Screw
E-clip
E
D
