Connector locations 5-21
5058-030
P/J567 4 Printhead interface contact LED printhead
P/J568 4 Printhead interface contact LED printhead
P/J569 4 Printhead interface contact LED printhead
P/J570 3 LED printhead Printhead interface contact
P/J571 3 LED printhead Printhead interface contact
P/J572 3 LED printhead Printhead interface contact
P/J573 3 LED printhead Printhead interface contact
P/J574 2 LED printhead Printhead interface contact
P/J575 2 LED printhead Printhead interface contact
P/J576 2 LED printhead Printhead interface contact
P/J577 2 LED printhead Printhead interface contact
P/J578 1 Printhead interface contact LED printhead
P/J579 1 Printhead interface contact LED printhead
P/J580 1 Printhead interface contact LED printhead
P/J581 1 Printhead interface contact LED printhead
Plug/Jack Callout Plug/jack description Connects to
