5-40 Service Manual
5058-030
P/J8396 5
Bridge PCBA
• Sensor (bridge top door interlock)
• Bridge drive motor
• Sensor (bridge media entrance)
• Bridge decurler cam clutch
• Sensor (decurler cam HP)
P8444 17 Bridge PCBA • Sensor (bridge top door interlock)
• Bridge drive motor
• Sensor (bridge media entrance)
• Decurler clutch
• Sensor (decurler cam HP)
P/J8460 12 Booklet output tray Booklet controller card assembly
P/J8461A 7 Finisher controller PCBA Media compiler guide
P/J8461B 7 Finisher controller PCBA Media compiler guide
P/J8500 13
Plug/Jack Callout Plug/jack description Connects to
