5-42 Service Manual
5058-030
P/J8307 5 Finisher controller PCBA • Sensor (punch carriage shift HP)
• Sensor (punch hole select)
• Sensor (punch cam front)
• Sensor (punch cam HP)
• Sensor (punch unit motor encoder)
• Sensor (punch unit side reg 1)
• Sensor (punch unit side reg 2)
P/J8308 2 Finisher controller PCBA • Stapler transport motor
• Sensor (stapler carriage HP)
• Stapler unit assembly,
P/J8309 18 Finisher controller PCBA • Media compiler guide
• Sensor (compiler media present)
• Sensor (front tamper HP)
• Sensor (rear tamper HP)
P/J8310 8 Finisher controller PCBA Bridge PCBA
P8311 14
P/J8313 11 Finisher controller PCBA Eject cover interlock switch
Sensor (finisher front door interlock)
P/J8314 10 Finisher controller PCBA Sensor (finisher front door interlock)
P/J8315 12 Finisher controller PCBA Finisher LVPS PCBA
P/J8316 9 Finisher controller PCBA Booklet controller card assembly
P/J8317 13 Finisher controller PCBA Booklet controller card assembly
P/J8376 16 Finisher controller PCBA Sensor (diverter gate)
P/J8389 3
Plug/Jack Callout Plug/jack description Connects to
