Lexmark C950 Service Manual

5-46 Service Manual
5058-030
Go Back
Previous
Next
P/J8405 4 Booklet controller card assembly • Booklet fold solenoid
• Sensor (booklet knife HP)
• Sensor (booklet knife folding)
• Sensor (booklet media exit)
• Booklet unit interface contact
• Sensor (booklet media exit)
• Sensor (booklet media entrance)
• Sensor (booklet rear tamper HP)
• Sensor (booklet front tamper HP)
• Sensor (booklet end guide HP)
P/J8406 10 Booklet controller card assembly • Booklet folding/exit motor
• Booklet rear tamper motor
• Booklet front tamper motor
• Booklet end guide drive motor
• Booklet paddle drive motor assembly
• Booklet stapler unit assembly
P/J8407 9 Booklet controller card assembly • Booklet folding/exit motor
• Booklet stapler unit assembly
P/J8408 8 Booklet controller card assembly • Booklet output tray
• Booklet diverter gate solenoid
P/J8411A 1 Booklet controller card assembly Booklet output tray
P/J8411B 1 Booklet controller card assembly Booklet output tray
P/J8429 5 Booklet unit interface contact Booklet controller card assembly
Plug/Jack Callout Plug/jack description Connects to

Lexmark C950 Specifications

General

Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Processor Speed	1.2 GHz
Connectivity	Ethernet, USB
Print Technology	Laser
Print Speed	50 ppm
Monthly Duty Cycle	300000 pages
Recommended Monthly Page Volume	5, 000 - 33, 000 pages
Memory	1024 MB
Hard Drive	Optional
Output Capacity	500 sheets
Interface	USB 2.0
Media Type	Plain paper, Card stock, Labels, Envelopes, Transparencies
Total Media Capacity	5140 sheets
Media Sizes	Letter, Legal, A4, A5, Executive, Folio, Statement
Operating Systems Supported	Windows, Mac, Linux
