7-66 Service Manual
5058-030
Assembly 63: Finisher—punch
Asm-
index
Part
number
Units/
mach
Units/
FRU
Description
63-1 40X0854 11Punch carriage shift motor
2 40X3905 21Sensor (punch unit side reg 1)
2 40X3905 21Sensor (punch unit side reg 2)
3 40X0862 11Punch waste box
4 40X7537 11Punch waste box bottle
5 40X0859 11Punch unit stopper
6 40X7438 11Sensor (punch unit motor encoder)
7 40X3943 11Punch unit motor
8 40X6865 113-hole punch unit assembly
8 40X3937 112-hole punch unit assembly
8 40X7536 114-hole punch unit assembly
9 40X0857 112/3 punch hammer sub-assembly
9 40X0858 112/4 punch hammer sub-assembly
10 40X7422 11Punch unit main cable
11 40X0855 11Punch carriage
