Assembly 85: High capacity feed (HCF)—media tray lift
Asm-
index
Part
number
Units/
mach
Units/
FRU
Description
85-1 40X0750 12HCF rear media guide kit includes:
HCF rear media guide
Screw
2 40X0751 12HCF front media guide kit includes:
HCF front media guide
Screw
3 40X0752 11HCF separation pad
4 40X0757 112HCF lift cable kit includes:
Lift cable (4)
Lift cable pulley (4)
Lift cable guide (4)
5 40X0754 17HCF media tray lift shaft kit includes:
Bushing 8 mm front
HCF media tray lift shaft
Bushing 8 mm rear
Washer
HCF media tray lift shaft cable pulley
HCF media tray lift shaft gear 10T
HCF media tray lift shaft gear 51T
6 40X0756 22HCF lift cable large pulley kit includes:
HCF lift cable large pulley
HCF lift cable large guide
7 40X0753 11HCF media tray lift gear bracket
