Parts catalog 7-93
5058-030
Go Back
Previous
Next
Assembly 86: High capacity feed (HCF)—media feed unit 1
Asm-
index
Part
number
Units/
mach
Units/
FRU
Description
86-1 40X0759 11HCF feed lift motor
2 40X0760 11HCF feed lift gear bracket
3 40X0913 11Ball bearing 6 mm
4 40X0761 13HCF separation drive gear kit includes:
HCF separation drive gear 25T
Bushing 6 mm
HCF separation drive gear 19T
5 40X6790 HCF pick roller raise lever
6 40X0763 13HCF media tray lift coupling kit includes:
HCF media tray lift coupling gear 40T
Spring
HCF media tray lift coupling
7 40X0771 11HCF separation roller shaft assembly
