Parts catalog 7-95

5058-030

Go Back

Assembly 87: High capacity feed (HCF)—media feed unit 2

Asm-

index

Part

number

Units/

mach

Units/

FRU

Description

87-1 40X0764 15HCF feed unit latch kit includes:

• HCF feed unit latch

• Spring

• HCF feed unit latch shaft

• HCF feed unit latch cover

2 40X0765 11HCF pick roller idler gear

3 40X0768 11Sensor (tray 5 media out)

3 40X0768 11Sensor (tray 5 media level)

4 40X0767 11HCF media out actuator

5 40X0770 13HCF feed unit roller kit includes:

• Feed roller

• Pick roller

• Separation roller

6 40X0769 12HCF pick roller shaft kit includes:

• HCF pick roller shaft assembly

• Bushing 6mm

7 40X0766 11HCF feed unit cable assembly
