Lexmark C950 - Page 466

4-38 Service Manual
5058-030
Go Back
Previous
Next
11. Remove the three screws (A) securing the CMYK toner dispense auger assembly to the printer.
12. Lift the four plastic gates and push them into their corresponding toners to prevent the toner from spilling.
13. Gently detach the lower portions (B) of the four augers from the developer housings.
A
2
1
