Lexmark C950 - Page 467

Repair information 4-39
5058-030
Go Back
Previous
Next
Warning: The lower portion (B) of the augers are prone to damage. Extra care is required in handling these
parts.
14. Disengage the CMYK toner dispense auger assembly and remove.
Note: After removal of the CMYK toner dispense auger assembly, be sure to clean up all visible toner spillage.
B
C
