GPIB Functions
Interface
Function Subset Description
Acceptor
Handshake
AH1 The instrument can receive multiline
messages across the GPIB from other
devices.
Controller C0 This instrument can be operated as a
device or as a controller.
Device Clear DC1 The instrument can respond to both
the DCL (Device Clear) interface
message and to the Selected Device
Clear (SDC) interface message when
the instrument is listen--addressed.
Device
Trigger
DT1 Device Trigger capability; the
instrument does respond to the GET
(Group Execute Trigger) interface
message.
Electrical E2 The instrument uses tri--state buffers,
which are optimal for high--speed data
transfer.
Listener L4 The instrument becomes a listener
when it detects the listen address
being sent over the bus with the ATN
line asserted. The instrument ceases
to be a listener and becomes a talker
when it detects the talk address being
sent over the bus with the ATN line
asserted.
Parallel Poll PP0 No Parallel Poll capability; the
instrument does not respond to PPC
(Parallel Poll Configure), PPD (Parallel
Poll Disable), PPE (Parallel Poll
Enable), or PPU (Parallel Poll
Unconfigure) interface messages, nor
does it send a status message when
the ATN and EOI lines are asserted
simultaneously.
Remote/
Local
RL1 The instrument can respond to both
the GTL (Go To Local) and LLO (Local
Lock Out) interface messages.
Service
Request
SR1 The instrument can assert the SRQ
line to notify the controller in charge
that it requires service.
Source
Handshake
SH1 The instrument can initiate multiline
messages to send across the GPIB to
other devices.
Tal ker T5 The instrument becomes a talker
when it detects the talk address being
sent over the bus with the ATN line
asserted. The instrument ceases to be
a talker and becomes a listener when
it detects the listen address being sent
over the bus with the ATN line
asserted. The instrument also ceases
to be a talker when it detects the talk
address of another device being sent
over the data lines with ATN asserted.
