Quality of Service (QoS) Commands
228
ProSAFE M7100 Managed Switches
diffserv
This command sets the DiffServ operational mode to active. While disabled, the DiffServ
configuration is retained and can be changed, but it is not activated. When enabled, DiffServ
services are activated.
no diffserv
This command sets the DiffServ operational mode to inactive. While disabled, the DiffServ
configur
ation is retained and can be changed, but it is not activated. When enabled, DiffServ
services are activated.
DiffServ Class Commands
Use the DiffServ class commands to define traffic classification. To classify traffic, you specify
Behavior Aggregate (BA), based on DSCP and Multi-Field (MF) classes of traffic (name, match
criteria)
This set of commands consists of class creation/deletion and matching, with the class match
commands specif
ying Layer 3, Layer 2, and general match criteria. The class match criteria are
also known as class rules, with a class definition consisting of one or more rules to identify the
traffic that belongs to the class.
Note: Once you create a class match criterion for a class, you cannot change
or delete the criterion. To change or delete a class match criterion, you
must delete and re-create the entire class.
The CLI command root is class-map.
class-map
This command defines a DiffServ class of type match-all. When used without any match
condition, this command enters the class-map mode. The <class-map-name> parameter is a
case-sensitive alphanumeric string from 1 to 31 characters uniquely identifying an existing
DiffServ class.
Format diffserv
Mode Global Config
Format no diffserv
Mode Global Config
