Quality of Service (QoS) Commands
237
ProSAFE M7100 Managed Switches
DiffServ Policy Commands
Use the DiffServ policy commands to specify traffic conditioning actions, such as policing and
marking, to apply to traffic classes
Use the policy commands to associate a traffic class that you define by using the class command
set with one or more QoS policy attributes. Assign the class/policy association to an interface to
form a service. Specify the policy name when you create the policy.
Each traffic class defines a particular treatment for packets that match the class definition. You
can as
sociate multiple traffic classes with a single policy. When a packet satisfies the conditions
of more than one class, preference is based on the order in which you add the classes to the
policy. The first class you add has the highest precedence.
This set of commands consists of policy creation/deletion, class addition/removal, and individual
policy attribut
es.
Note: The only way to remove an individual policy attribute from a class
instance within a policy is to remove the class instance and re-add it to
the policy. The values associated with an existing policy attribute can be
changed without removing the class instance.
The CLI command root is policy-map.
assign-queue
This command modifies the queue id to which the associated traffic stream is assigned. The
<queueid> parameter is an integer from 0 to n-1, where n is the number of egress queues
supported by the device.
drop
This command specifies that all packets for the associated traffic stream are to be dropped at
ingress.
Format assign-queue <queueid>
Mode Policy-Class-Map Config
Incompatibilities Drop
Format drop
Mode Policy-Class-Map Config
Incompatibilities Assign Queue, Mark (all forms), Mirror, Police, Redirect
