Switching Commands
90
ProSAFE M7100 Managed Switches
show port-channel
This command displays an overview of all port-channels (LAGs) on the switch.
show port-channel counters
Use this command to display port channel counters for a specified LAG interface or physical
interface.
Format show port-channel {<logical slot/port> | all}
Mode • Privileged EXEC
• User EXEC
Term Definition
Logical Interface Valid slot and port number separated by forward slashes.
Port-Channel
Name
The name of this port-channel (LAG). You may enter any string of up to 15 alphanumeric
charac
ters.
Link State Indicates whether the Link is up or down.
Admin Mode May be enabled or disabled. The factory default is enabled.
Type The status designating whether a particular port-channel (LAG) is statically or dynamically
maint
ained.
• S
tatic - The port-channel is statically maintained.
• Dynamic - The port-channel is dynamically maintained.
Mbr Ports A listing of the ports that are members of this port-channel (LAG), in slot/port notation.
There c
an be a maximum of eight ports assigned to a given port-channel (LAG).
Device Timeout For each port, lists the timeout (long or short) for Devic
e Type (actor or partner).
Port Speed Speed of the port-channel port.
Ports Active This field lists the ports that are actively participating in the port-channel (LAG).
Load Balance
Option
The load balance option associated with this LAG. See port-channel load-balance on page 86.
Local Preference
Mode
Indicates whether the local preference mode is enabled or disabled.
Format show port-channel {<lag-id> | <unit/slot/port>} counters
Mode Privileged EXEC
Term Definition
Local Interface The valid slot/port number.
Channel Name The name of this port-channel (LAG).
Link State Indicates whether the Link is up or down.
