Utility Commands
441
ProSAFE M7100 Managed Switches
The command is not persistent across a reboot cycle.
capture (Global Config command)
Use this command to configure file capture options. The command is persistent across a reboot
cycle.
no capture
Use this command to reset the capture mode to remote mode.
Format capture {start | stop} {transmit | receive | all}
Mode Privileged EXEC
Default Remote
Format capture {file | remote | line}
Mode Global Config
Parameter Description
file In capture file mode, the captured packets are stored in a file on NVRAM. The maximum
file size def
aults to 524,288 bytes. The switch can transfer the file to a TFTP server via
TFTP, SFTP, SCP via CLI, web and SNMP. The file is formatted in PCAP format, is named
cpuPktCapture.pcap, and can be examined using network analyzer tools such as
Wireshark® by Ethereal®. Starting a file capture automatically terminates any remote
capture sessions and line capturing. After the packet capture is activated, the capture
proceeds until the capture file reaches its maximum size, or until the capture is stopped
manually using the CLI command capture stop.
remote In remote capture mode, the captured packets are redirected in real time to an external
c
omput
er running the Wireshark tool for Microsoft® Windows®. A packet capture server
runs on the switch side and sends the captured packets via a TCP connection to the
Wireshark tool. The remote capture can be enabled or disabled using the CLI. There should
be a Windows computer with the Wireshark tool to display the captured file. When using
the remote capture mode, the switch does not store any captured data locally on its file
system. You can configure the IP port number for connecting Wireshark to the switch. The
default port number is 2002. If a firewall is installed between the Wireshark PC and the
switch, these ports must be allowed to pass through the firewall. You must configure the
firewall to allow the Wireshark computer to initiate TCP connections to the switch. If the
socket connection to Wireshark has been established, the captured CPU packets are
written to the data socket. Wireshark receives the packets and processes it to display. This
continues until the session is terminated by either end. Starting a remote capture session
automatically terminates the file capture and line capturing.
line In capture line mode, the captured packets are saved in real-time mode into the RAM and
c
an be displayed on the CLI. S
tarting a line capture automatically terminates any remote
capture session and capturing into a file.
Format no capture
Mode Global Config
