Xerox Phaser 7100 Service Manual

Parts List
Xerox Internal Use Only Phaser 7100 Service Manual 5-57
Parts List 14.2 Duplex (2 of 3)
Item Description Part Number
1. Duplex Earth Motor (REP 14.2 Duplex Motor on page 4-250)
2. Duplex Motor Bracket
3. Duplex Motor Cover
4. Duplex Lock Lever
5. Earth Bearing
6. Duplex Pinch Roller
7. Roller 1 Pinch Spring
8. Roller 2 Pinch Spring
9. Duplex Roller (REP 14.3 Duplex Roller on page 4-251)
10. Duplex Roller Gear
11. Idle Gear 22
12. Bearing
13. Clutch Shaft
14. Idle Clutch Gear
15. Idle Gear 16
16. Swing Bracket Assembly
17. Swing Spring
18. Idle Gear 17
19. Duplex Collar
20. Duplex In Clutch Assembly (REP 14.4 Duplex In Clutch Assembly/
Duplex Drive Gear Assembly Kit on page 4-254)
21. Duplex B Bracket Assembly
22. Duplex Drive Gear Assembly Kit (with 12-21) (REP 14.4 Duplex In
Clutch Assembly/ Duplex Drive Gear Assembly Kit on page 4-254)
604K59701
23. Caution Label
98. Duplex Motor Assembly Kit (with 1, 23) (REP 14.5 Duplex Motor
Assembly on page 4-256)
604K76950

Xerox Phaser 7100 Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 52, 000 pages
Processor	667 MHz
Memory (Standard)	256 MB
Paper Input Capacity (Maximum)	2, 050 sheets
Paper Output Capacity	250 sheets
Duplex Printing	Automatic
Type	Color Laser Printer
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Supported Media Sizes	A4, A5, B5, Letter, Legal
First Page Out (Black)	9 seconds
First Page Out (Color)	9 seconds
Print Languages	PCL 6, PostScript 3
Network Connectivity	Ethernet
Print Speed	Up to 30 ppm
