Error Troubleshooting
Phaser 7100 Service Manual Xerox Internal Use Only2-392
124-345 Billing Meter Type Restoration Fail
When at least one Billing Meter Type is not matched and the machine automatic correction has failed
to correct the problem.
Applicable Fault Code
• 124-345: Billing Meter Type Fail (at least 1 location is mismatched, unable to correct
automatically)
Initial Actions
• Power cycle the printer.
• If the problem persists, perform the following procedure
.
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
• MCU PWB, PL 12.1.15
• I/P PWB, PL 12.4.1
Troubleshooting Procedure
Step Actions and Questions
1. Perform DC131 NVM Read/ Write on page 2-45 to compare the following NVM values.
• If the values of 720-002 and 720-062 are the same, replace the MCU PWB (REP 12.4 MCU PWB
on page 4-206).
• If the values are different, replace the I/P PWB (REP 12.17 Image Processor (I/P) PWB on
page 4-228).
To Next Page
