Error Troubleshooting
Phaser 7100 Service Manual Xerox Internal Use Only2-262
Tray 4 Motor Fail
Option Feeder 4 Motor error.
Applicable Fault Code
• 074-310: Tray 4 Motor Fail
Initial Actions
• Power cycle the printer.
• If the problem persists, perform the following procedure.
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
• MCU PWB, PL 12.1.15
• Feeder Motor (Option Drive Assembly), PL 15.2.28
•Option Left Feeder Harness Assembly, PL 15.2.31
• Feeder PWB, PL 15.2.33
• 550-Sheet Feeder on page 7-64
Troubleshooting Procedure
Step Actions and Questions
1. Refer to Option Feeder Motor on page 2-439.
To Next Page
