Xerox Phaser 7100

Error Troubleshooting
Xerox Internal Use Only Phaser 7100 Service Manual 2-323
116-315 ESS RAM DIMM #1 W/R Check Fail
An error was detected when performing W/R to the I/P PWB RAM DIMM #1.
Applicable Fault Code
• 116-315: ESS RAM DIMM #1 W/R Check Fail
Initial Actions
• Power cycle the printer.
• If the problem persists, perform the following procedure
.
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
• 1 GB DDR2 DIMM (Standard), PL 12.4.2
• I/P PWB, PL 12.4.1
Troubleshooting Procedure
Step Actions and Questions
1. • Remove and reinstall the I/P PWB RAM DIMM #1.
• Replace the I/P PWB RAM DIMM #1 (REP 12.18 Memory (Standard) on page 4-232).
• Replace the I/P PWB (REP 12.17 Image Processor (I/P) PWB on page 4-228).
