Xerox Phaser 7100

Error Troubleshooting
Xerox Internal Use Only Phaser 7100 Service Manual 2-279
(K) Imaging Unit Error: Life End
Imaging Unit error has occurred due to one of the following problems.
• Indicates that it is time to replace the Imaging Unit.
• The Imaging Unit life end is detected.
Applicable Fault Codes
• 091-402: Imaging Unit Quality Life End
• 091-913: Imaging Unit K End Of Life
Initial Actions
• Check the Imaging Unit life. Access CWIS > Status > Consumables.
• If the problem persists, perform the following procedure.
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
• Imaging Unit (K), PL 6.1.4
Troubleshooting Procedure
Step Actions and Questions
1. Replace the Imaging Unit (K) (REP 6.0 Imaging Unit (Y/ M/ C/ K) on page 4-121).
