General and Operation Overview
Xerox Internal Use Only Phaser 7100 Service Manual 1-41
Paper Path
Y
M
C
K
: Laser Beam
: Paper Feeding
s7100-426
Bias Charge Roller (BCR)
Laser Unit
Magnet Roller
1st BTR
Erase Lamp
Cleaning Blade
Cleaning Roller
Cleaning Blade
Fuser Unit
2nd BTR (Transfer Roller)
Detack Saw
